Product Overview
This working table in laboratory is designed for professional laboratory environments and can be configured as a central bench or side bench.
It is widely used for experimental operations, sample storage, and equipment placement, meeting the functional requirements of scientific research, testing, and other laboratory applications.
Materials & Structure
The cabinet system is made of 18mm E1 grade melamine-faced particle board, which is environmentally friendly and structurally stable. PVC waterproof edge banding is applied to prevent moisture damage and deformation. The standard cabinet color is modern gray, while door panel colors can be customized. Aluminum alloy straight-line handles are used for a simple and durable finish.
The steel frame is constructed from 40 × 60 × 1.2mm galvanized steel tubes, formed through welding and finished with epoxy resin electrostatic powder coating and high-temperature curing. This provides strong adhesion, scratch resistance, and excellent acid and alkali resistance, ensuring long-term stability for the working table in laboratory.
The worktop uses a 12.7mm solid phenolic resin board, which is resistant to chemicals, heat, and easy to clean, making it suitable for demanding laboratory environments.
Hardware accessories include 16-inch silent drawer slides and 115° opening hinges, ensuring smooth and durable daily operation.
Manufacturing Process
The production process uses CNC precision cutting for high dimensional accuracy. Steel components are welded using spot welding and argon arc welding to ensure structural strength. The surface coating is applied in a fully automated spray booth using imported spray equipment, followed by high-temperature curing for a uniform and durable finish. These processes ensure the long service life and stability of the working table in laboratory under intensive use.
Structure & Function
This working table in laboratory adopts a modular knock-down structure, making it easy to transport, install, and handle in narrow laboratory spaces such as corridors and elevators.
The system supports flexible combination, allowing it to be configured as either a central bench or side bench according to laboratory layout requirements.
Optional functional modules include hanging cabinets, drawer units, keyboard trays, and open storage compartments, enabling customized configurations based on different experimental needs.
Dimensions
Multiple sizes are available, with customizable length, width, and height. Final dimensions can be adjusted according to laboratory layout and functional requirements.
This working table in laboratory system provides a flexible, durable, and professional solution for modern laboratory environments, combining structural strength, modular design, and practical functionality.
